GRADIENTE _ IDENTIFICATION NUMBER PART OF PCBs

     The PCBs of plasma televisions have label that identifies the NAME of PCI and / or your PART NUMBER.
     Also use this information to identify and correct application of PCIs.

Below are examples of labels that can be found in PCBs.

• PCI BUFFER Y-DRIVE SUPERIOR/INFERIOR (PLT-4270)  Part Number [95A2260001901].
•   Keyboard (PLT-4270)  Part Number [95A0590001901]

• Y- REGULATOR [PLT-4270] Part Number (95A8397001901).

• PCI – SOURCE. (PLT-4270) Part Number [95A3400001901]

• Z-PCI controller {PLT-4270}.  Part Number (95A8398001901)

• Video Processor {PLT-4270}.  Part Number (95A5180001901).  ICs at positions N600 and N601. Coils at positions L417 and L418.

• Controller PCI {PLT-4270}.  Part Number ( 95A2230001901).

• TUNER / AV PCI {PLT-4270}.  Part Number (95A2300001901)

• X-Drive Buffers. {PLT-4270}. Part numbers (95A2250001901 &  95A2240001901)
