42 INCH HD PCB BOARD LAY OUT
PRINTED CIRCUIT BOARD INFORMATION TABLE
Board Name
|
Part Number
|
Function
|
C1
|
TNPA2428
|
Data
Drive (Upper Left)
|
C2
|
TNPA2429
|
Data
Drive (Upper Right)
|
C3
|
TNPA2430
|
Data
Drive (Lower Right)
|
C4
|
TNPA2431
|
Data
Drive (Lower Left)
|
D1
|
TZTNP01LLSB
|
Format
Converter
|
D2
|
TNPA2427
|
Plasma
AI Sub-Field Processor
|
F
|
TNPA2444
|
Line
filter
|
H3
|
TNPA2249
|
Speaker
terminal
|
HX
|
TZTNP01LLSU
|
PC type
Input terminal
|
HZ
|
TXNHZ40JJS
|
RCA type
Input terminal
|
P
|
TXN/P10LLS
|
Power
supply
|
P3
|
TNPA2439
|
Drive
voltage oscillator
|
P5
|
TNPA2440
|
Primary
oscillator
|
P6
|
TNPA2441
|
PFC
oscillator
|
P7
|
TNPA2442
|
Drive
voltage protection
|
P8
|
TNPA2443
|
Process
voltage protection
|
S1
|
TNPA2283AC
|
Power
switch
|
SC
|
TNPA2434
|
Scan out
|
SD
|
TNPA2433
|
Scan
connection (Lower)
|
SS
|
TNPA2435
|
Sustain
out
|
SS2
|
TNPA2435
|
Sustain
connection (Upper)
|
SS3
|
TNPA2437
|
Sustain
connection (Lower)
|
SU
|
TNPA2432
|
Scan
connection (Upper)
|
V1
|
TNPA2282AC
|
Front
SW. & Remote receiver
|
Z
|
TNPA2445
|
Audio
out
|
