SPARE PARTS
Note that when ordering FRU parts, you should check the most up-to-date information available on your regional web or channel. For whatever reasons a part number is changed, it will NOT be noted on the printed service guide. For Acer authorized service providers, your Acer office may have a different part number code from those given in the FRU list of this printed service guide. You MUST use the local FRU list provided by your regional Acer office to order FRU parts for service.
NOTE: To scrap or
to return the defective parts, you should follow the local government ordinance
or regulations on how to dispose them properly, or follow the rules set by your
regional Acer office on how to return it.
DESCRIPTION: HH6 IR/B ASSY. ACER PART NUMBER: 55.M12V7.002
POWER BOARD: PWR 157W,DPS-157DP A(90~264VAC. ACER PART NUMBER: 55.M11V7.001
KEYPAD BOARD: HH6 KEYPAD&AV3/B ASSY. ACER PART NUMBER: 55.M12V7.001
IO/TURNER BOARD -PAL EU: HH6 IO/B ASSY(EU). ACER PART NUMBER: 55.M12V7.004
MAIN BOARD AT 2603 - PAL EU: HH2 M/B ASSY(EU). ACER PART NUMBER: 55.M11V7.006
LVDS CABLE – QDI PANEL: CABLE ASSY
HH6 LVDS(QDI). ACER PART NUMBER: 50.M11V7.001
INVERTER CABLE – QDI PANEL: CABLE ASSY HH6 INVERT(QDI). ACER PART NUMBER: 50.M11V7.002
CABLE - MB TO POWER: CABLE ASSY VA1 MBPWR. ACER PART NUMBER: 50.M01V7.004
CABLE - POWER TO AUDIO: CABLE ASSY HH6 PW-AUDIO. ACER PART NUMBER: 50.M11V7.005
SPEAKER CABLE: CABLE ASSY HH6 SPEAKER. ACER
PART NUMBER: 50.M11V7.006
CABLE - MB TO AV3: CABLE ASSY HH6 MB-AV3. ACER
PART NUMBER: 50.M11V7.007
CABLE - KEY TO IR TO MB: CABLE ASSY
HH6 KEY-IR. ACER PART NUMBER: 50.M11V7.008
CABLE – GROUND: CABLE ASSY HH6 GND-GND. ACER PART NUMBER: 50.M11V7.009
CABLE - IRTO GROUND: CABLE ASSY VA1
IBGND. ACER PART NUMBER: 50.M01V7.011
